20Khz Ultrasonic Splicer Metal Cable Joining Machine With HIgh Power 4000W

20Khz Ultrasonic Splicer Metal Cable Joining Machine With HIgh Power 4000W

MOQ: 1 unit
Price: Negotation
Standard Packaging: Packed in wooden carton
Delivery Period: 15 workdays
Payment Method: T/T, Western Union
Supply Capacity: 1000 pcs per month
Detail Information
Place of Origin
China
Brand Name
QRsonic
Certification
CE
Model Number
QR-X2040A
Products Name:
Ultrasonic Wire Splicer Welding Machine
Frequency:
20KHZ
Power:
4000W
Voltage:
220V
Welding Area:
1-30mm2
Air Pressure:
0.05-0.9MPa
Generator Size:
540*380*150mm
Dimension Of Horn:
550*250*240mm
Highlight:

Ultrasonic Wire Harness Welding Machine 20Khz

,

4kW Ultrasonic Wire Harness Welding Machine

Product Description

20Khz Ultrasonic Splicer Metal Cable Joining Machine with HIgh Power 4000W


Description:

20Khz 4000w ultrasonic seamless wire harness welding, replace the traditional welding/bonding process, low cost, clean and pollution-free and will not damage the workpiece. The welding process is stable, the welding speed is fast, the welding strength is high, and the sealing performance is good. Low requirements for welding metal surface, can be welded by oxidation or electroplating.
The ultrasonic wire harness welding machine is mainly composed of an ultrasonic generator, a transducer, a welding head and a pneumatic part. It is suitable for the connection of transistors, integrated circuits and electrolytic capacitor components. The system is easy to install, install and operate. The system can adjust the sequence to complete the wire harness welding of 0.5 to 30mm2 cross-sectional area.




Parameters:



Item No QR-X2020A QR-X2030A QR-X2040A
Power 2000W 3000W 4000W
Welding Area 0.5-16mm2 0.5-20mm2 1-30mm2
Air Pressure 0.05-0.9MPa 0.05-0.9MPa 0.05-0.9MPa
Frequency 20KHZ 20KHZ 20KHZ
Voltage 220V 220V 220V
Weight of horn 18KG 22KG 28KG
Dimension of Horn 530*210*230mm 550*220*240mm 550*250*240mm
Generator Size 540*380*150mm 540*380*150mm 540*380*150mm




Advantage:



1. Energy saving and environmental protection

2. No ventilation device for dissipating smoke

3. Low cost, high efficiency

4. Easy to achieve automated production

5. High welding strength and firm bonding

6. Beautiful solder joints, can achieve seamless welding, moisture-proof and waterproof, good air tightness Note: Thermosetting plastics can not be ultrasonically welded.

7. Ultrasonic welding is radiation-free and will not cause direct radiation damage to the human body. If it is harmful, it is a certain noise when ultrasonic welding plastic. The noise is different according to the frequency. The noise of 20KHZ equipment is relatively high. Smaller, the application of ultrasonic plastic welding technology in the plastics industry has become increasingly common. The application of this technology can replace the flux, adhesive, pinning or other mechanical fixing methods required in the past, thereby increasing production efficiency and reducing costs. The principle of ultrasonic welding machine is to generate 20KHz (or 15KHz) high-voltage and high-frequency signals from the generator. Through the energy conversion system, the signal is converted into high-frequency mechanical vibration, which is applied to the workpiece of plastic products and passes through the surface of the workpiece and the intrinsic molecules. Friction causes the temperature of the interface to rise, and when the temperature reaches the melting point of the workpiece itself, the workpiece interface is rapidly melted, and then filled in the gap between the interfaces; when the vibration stops, the workpiece is simultaneously cooled and shaped under a certain pressure, A perfect weld is achieved.

8. Fast welding speed, high welding strength and good sealing; replace traditional welding/bonding process, low cost, clean and pollution-free and will not damage the workpiece; stable welding process, all welding parameters can be tracked and monitored by software system Once the fault is discovered, it is easy to eliminate and maintain.

9. The welding material does not melt and is not fragile.

10. Good electrical conductivity after soldering, very low or nearly zero resistivity.

11. Low requirements on the surface of the welded metal, oxidation or plating can be welded.

12. The welding time is short and does not require any flux, gas or solder.
