| Products Name: | Ultrasonic Metal Welding | Frequency: | 20KHZ |
|---|---|---|---|
| Power: | 3000W | Voltage: | 380V |
| Welding Speed: | 2-15m/min | Dimension Of Generator: | 540*380*150mm |
| High Light: | ultrasonic welding process,ultrasonic welding machine |
||
Ultrasonic Copper Sheet Aluminum Sheet Cooper Tube Aluminum Tube Roll Welding Machine
Description:
The ultrasonic welding system is mainly composed of an ultrasonic generator, a transducer, a welding head and a pneumatic part. The system is easy to install, install and operate. All important welding parameters ensure an extremely high weld quality.
Principle of Ultrasonic metal roll welding machine construction:
Solar metal metallurgy using super-new ultrasonic metal welding technology
Ultrasonic generator + continuous rolling welding tool head (welding head)
Special copper and aluminum tube clamping mold, the fixture can adapt to different sizes of copper or aluminum tubes; copper or aluminum sheet pressing device; tool head (welding head) lowering pneumatic device; servo accurate control system (control motor lateral + The welding head rotates. The high-frequency vibration is transmitted through the ultrasonic system, and a certain pressure is applied through the cylinder to transmit the ultrasonic waves to the two objects to be welded to achieve superior welding results.
Specifications:
| Item No | QR-G2030A |
| Power | 3000W |
| Air Pressure | 0.05-0.9MPa |
| Frequency | 20KHZ |
| Voltage | 380V |
| Dimension of device | Customized |
| Dimension of Generator | 540*380*150mm |
| Working Mode | Continuous |
| Welding Speed | 2-15m/min |
Ultrasonic solar metal metal welding machine welding process:
1. Manually place the workpiece (copper plate copper and copper tube) into the lower tooling on the equipment workbench;
2. Press the start switch, the device automatically presses the copper plate and the copper tube, and the seam welding starts;
3. After the welding is finished, the equipment automatically opens the pressing device and automatically moves the welding workpiece to a position (the moving distance can be adjusted according to the spacing of the copper pipe). The next welding starts, and the analogy will require the number of welding to be completed step by step;
4. After the whole welding is completed, the equipment will automatically open all the pressing devices and automatically restore the lower tooling to the initial position;
5 Ultrasonic copper plate copper sheet and copper tube seam welder The operator removes the welded workpiece and completes the welding.
Function of Ultrasonic solar metal metal welding machine:
1. Simultaneous welding of full-page solar panels and single copper tubes and copper or aluminum sheets
2. servo control system, the welding direction can be easily set by the touch screen;
3. Ultrasonic solar metal metal welding machine is ideal for welding similar or different conductive alloys and non-ferrous metal production equipment of different thicknesses;
4. ultrasonic solar metal metal welding machine welding changes can be accurately monitored and controlled, welding consistency;
5. modular design, easy to install, easy to maintain, welding height adjustment mechanism is easy to operate, accuracy up to 0.02MM;
Ultrasonic Copper Sheet Aluminum Sheet Cooper Tube Aluminum Tube Roll Welding Machine
