Place of Origin: | China |
---|---|
Brand Name: | QRsonic |
Certification: | CE |
Model Number: | QR-F2030A |
Minimum Order Quantity: | 1 unit |
Price: | Negotation |
Packaging Details: | Packed in wooden case |
Delivery Time: | 15 workdays |
Payment Terms: | T/T, Western Union |
Supply Ability: | 2000 unit per month |
Products Name: | Ultrasonic Metal Welding | Frequency: | 20KHZ |
---|---|---|---|
Power: | 3000W | Voltage: | 220V |
Air Pressure: | 0.05-0.9Mpa | Dimension Of Generator: | 540*380*150mm |
Highlight: | ultrasonic metal welding equipment,ultrasonic welding process |
3000w Ultrasonic Metal Cutting and Sealing Machine for Diameter 12mm Tube
Description:
The copper tube ultrasonic sealing machine transmits high-frequency vibration waves to two metal surfaces to be welded, and under pressure, the two metal surfaces rub against each other to form a fusion between the molecular layers, which has the advantages of being fast, Energy saving, high fusion strength, good electrical conductivity, no spark, near cold processing
Specifications:
Item No | QR-F2030A |
Power | 3000W |
Diameter of Tube | Φ2-12mm |
Air Pressure | 0.05-0.9MPa |
Frequency | 20KHZ |
Voltage | 220V |
Weight of horn | 26KG |
Dimension of Horn | 460*220*1000mm |
Generator Size | 540*380*150mm |
Features:
1) Handheld copper tube ultrasonic sealing is small in size; light in weight; beautiful in appearance
2) Handheld copper tube ultrasonic sealing machine has good conductivity after welding; welding is safe and reliable
3), does not change the metal structure of the welding object itself; high welding quality
4), the welding machine has a high degree of automation; the welding consistency is good; the quality is guaranteed
Attentions :
1. For different materials and sizes, we need strict technical indicators. Let us take the copper tube of the refrigerator as an example: the copper tube of the refrigerator generally uses φ6mm and the wall thickness of 0.75mm copper tube. After ultrasonic welding, the ultra-thin place should be controlled at 0.8-0.9mm. . If the welder cannot meet this requirement steadily, it is a garbage machine.
2. The high-quality welder has two ultrasonic amplitude control functions, one for flattening and one for welding. If the welder cannot meet this requirement and proves that the generator is not controllable, it must be a garbage machine.
3. In the refrigerator application, the life of the welding head must reach more than 30,000 times. Under certain extreme conditions, our welding head can achieve 200,000 times.
