15Khz Ultrasonic Ultrasonic Piezoelectric Transducer Trumpet Type For Welding Equipment
Products

Ultrasonic Metal Welding

Ultrasonic Spray Coating Machine

Ultrasonic Indium Coating

Ultrasonic Sonochemistry Equipment

Ultrasonic Melt Treatment

Ultrasonic Assisted Machining

Ultrasonic Processing Equipment

Ultrasonic Plastic Welding Machine

Ultrasonic Sewing Machine

Ultrasonic Cutting Machine

Ultrasonic Welding Converter

Ultrasonic Welding Transducer

Ultrasonic Piezoelectric Transducer

Ultrasonic Oscillator

Ultrasonic Wave Generator

Ultrasonic Wire Harness Welding Machine

Ultrasonic Metal Welding Machine
Contact Us
WeChat
Contact Now
15Khz Ultrasonic Ultrasonic Piezoelectric Transducer Trumpet Type For Welding Equipment
  • name
  • name
  • name
  • name

15Khz Ultrasonic Ultrasonic Piezoelectric Transducer Trumpet Type For Welding Equipment

MOQ: 1 pcs
Price: Negotation
Standard Packaging: Packed in carton
Delivery Period: 3 workdays
Payment Method: T/T, Western Union
Supply Capacity: 2000pcs per month
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
QRsonic
Certification
CE
Model Number
QR-5015-6BD
Products Name:
Ultrasonic Welding Transducer
Frequency:
15 Khz
Output Power:
2600 Watt
Joint Bolt:
1/2-20UNF
Ceramic Disc Diameter:
50mm
Qty Of Ceramic Discs:
6pcs
Capacitance:
17-25nf
Amplitude:
10 Um
Highlight:

piezoelectric ceramic transducer

,

high frequency ultrasound transducer

Product Description

15Khz Ultrasonic Pizo Electric Transducer Trumpet Type for Welding Equipment





Description:



Ultrasonic transducer is a device that can convert high-frequency electrical energy into mechanical energy. Generally, it is magnetostrictive and piezoelectric ceramic. The power is output to the ultrasonic generator, and then to the ultrasonic transducer, and ultrasonic waves are generally generated by the ultrasonic derivation and receiving device.



The composition of the ultrasonic transducer includes: an outer casing, a matching layer, that is, an acoustic window, a piezoelectric ceramic disk transducer, a backing, and an extraction cable, and is characterized in that it further comprises an array receiver, which is led by a cable, a transducer, Metal ring, rubber gasket





Specifications:



Model QR-5015-6BD
Frequency 15 khz
Output power 2600 watt
Joint bolt 1/2-20UNF
Ceramic disc Diameter 50mm
Qty of ceramic discs 6pcs
Capacitance 17-25nf
Amplitude 10 um
Application Plastic welding machine





Functional structure of Transducer:



The ultrasonic transducer comprises a casing (1), a matching layer, ie, an acoustic window (2), a piezoelectric ceramic disk transducer (3), a backing (4), and an outgoing cable (5), characterized in that it further comprises Cymbal array receiver consisting of an extraction cable (6), 8 to 16 Cymbal transducers (7), metal rings (8), (9) and rubber washers (10); Cymbal array receivers are located on the disc Above the piezoelectric transducer 3; the piezoelectric ceramic disk transducer acts as a basic ultrasonic transducer for transmitting and receiving ultrasonic signals; the Cymbal array receiver is located above the disk piezoelectric transducer. As an ultrasonic receiver, it is used to receive Doppler echo signals outside the band of the disk transducer.





15Khz Ultrasonic Pizo Electric Transducer Trumpet Type for Welding Equipment



15Khz Ultrasonic Ultrasonic Piezoelectric Transducer Trumpet Type For Welding Equipment 0





15Khz Ultrasonic Ultrasonic Piezoelectric Transducer Trumpet Type For Welding Equipment 1

Tags:

ultrasonic high power transducer,

piezoelectric ceramic transducer,

high frequency ultrasound transducer
