Stepped Column 1200w Ultrasonic Piezoelectric Transducer , 24 Khz Ultrasonic Transducer With 192mm Length

Stepped Column 1200w Ultrasonic Piezoelectric Transducer , 24 Khz Ultrasonic Transducer With 192mm Length

MOQ: 1 pcs
Price: Negotation
Standard Packaging: Packed in carton
Delivery Period: 3 workdays
Payment Method: T/T, Western Union
Supply Capacity: 2000pcs per month
Detail Information
Place of Origin
China
Brand Name
QRsonic
Certification
CE
Model Number
QR-5024-4JZ
Products Name:
Ultrasonic Welding Transducer
Frequency:
24 Khz
Output Power:
1200 Watt
Joint Bolt:
M12
Ceramic Disc Diameter:
50mm
Qty Of Ceramic Discs:
4pcs
Capacitance:
11-12nf
Amplitude:
10 Um
Highlight:

piezoelectric transducer ultrasound

,

ultrasonic piezo transducer

Product Description

Stepped Column 24Khz 1200W Ultrasonic Transducer with 192mm Length





Description:



Due to different processing methods and requirements, the working mode of the transducer can be roughly divided into continuous work (lace machine, CD set machine, zipper machine, metal welding, etc.) and pulse type work (such as plastic welding machine). Different working methods The requirements for the transducer are different. In general, continuous operation has almost no pause time, but the operating current is not very large, the pulse operation is intermittent, there is a pause, but the instantaneous current is very large. On average, the power of both states is large.





Specifications:



Model QR-5024-4JZ
Frequency 24khz
Output power 1200 watt
Joint bolt M12
Ceramic disc Diameter 50mm
Qty of ceramic discs 4pcs
Capacitance 11-12nf
Amplitude 10 um
Application Plastic welding machine





The difference between high frequency and ultrasound:


High frequency and ultrasonic are two different concepts. High frequency refers to electromagnetic waves with a frequency greater than 100Khz, and ultrasonic waves refers to sound waves with a frequency exceeding 20 kHz. The high-frequency welding principle and welding principle are different from those of ultrasonic waves. High-frequency electromagnetic waves use high-frequency electromagnetic fields to make the internal molecules collide with each other to produce high temperature to achieve welding and welding. Ultrasonic waves generate a large amount of heat by the principle of frictional heat generation. To achieve the purpose of welding and welding.
High-frequency applications are widely used, so there are high-frequency plastic welding machines, high-frequency plastic-plastic fuses, high-frequency folding box indenters, high-frequency embossing machines, and high-frequency heating machines.
High frequency is a high frequency wave. High frequency and ultrasonic are two different concepts. High frequency refers to electromagnetic waves with a frequency greater than 100Khz. Dongguan ultrasonic refers to sound waves with a frequency exceeding 20 kHz. The high-frequency welding principle and welding principle are different from the ultrasonic wave. High-frequency electromagnetic waves use high-frequency electromagnetic fields to make the internal molecules collide with each other to produce high temperature to achieve welding and welding. Ultrasonic waves generate a large amount of heat by using the principle of frictional heat generation. To achieve the purpose of welding and welding.
The high frequency is generated by the self-excited oscillator of the electron tube, so that the processed plastic is in the high-frequency electric field between the upper and lower electrodes, and the internal molecules generate the force motion friction, and the welding purpose and the welding effect are obtained under the pressure of the mold.





Stepped Column 24Khz 1200W Ultrasonic Transducer with 192mm Length





Stepped Column 1200w Ultrasonic Piezoelectric Transducer , 24 Khz Ultrasonic Transducer  With 192mm Length 0





Stepped Column 1200w Ultrasonic Piezoelectric Transducer , 24 Khz Ultrasonic Transducer  With 192mm Length 1
