35Khz High Frequency Ultrasonic Transducer 500W With 2PCS Ceramics 35mm PZT8
  • name
  • name
  • name
  • name

35Khz High Frequency Ultrasonic Transducer 500W With 2PCS Ceramics 35mm PZT8

MOQ: 1 pcs
Price: Negotation
Standard Packaging: Packed in carton
Delivery Period: 3 workdays
Payment Method: T/T, Western Union
Supply Capacity: 2000pcs per month
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
QRsonic
Certification
CE
Model Number
QR-3535-2BD
Products Name:
Ultrasonic Welding Transducer
Frequency:
35 Khz
Output Power:
500 Watt
Joint Bolt:
M8*1
Ceramic Disc Diameter:
35mm
Qty Of Ceramic Discs:
2pcs
Capacitance:
4.5-5nf
Amplitude:
6um
Highlight:

ultrasonic piezo transducer

,

high frequency ultrasonic transducer

Product Description

PZT8 35Khz 500W Ultrasonic Welding Transducer with 2PCS Ceramics





Description:



The ultrasonic sensor is a sensor that is developed using the characteristics of ultrasonic waves. Ultrasonic wave is a kind of mechanical wave with a vibration frequency higher than that of sound waves. It is generated by the vibration of the transducer wafer under the excitation of voltage. It has high frequency, short wavelength, small diffraction phenomenon, especially good directivity, and can be ray oriented. Characteristics such as communication. Ultrasonic waves have a great ability to penetrate liquids and solids, especially in sunlight-opaque solids, which can penetrate depths of several tens of meters. When an ultrasonic wave hits an impurity or an interface, it will produce a significant reflection to form a reflection into an echo, which can produce a Doppler effect when it hits a moving object.





Specifications:



Model QR-3535-2BD
Frequency 35khz
Output power 500 watt
Joint bolt M8*1
Ceramic disc Diameter 35mm
Qty of ceramic discs 2pcs
Capacitance 4.5-5nf
Amplitude 6 um
Application Plastic welding machine





Ultrasonic transducer process differentiation can be divided into the following points:



1. It can be identified from the manufacturing process and appearance of the ultrasonic transducer. The transducer indirectly shows that the company pays attention to the quality of the product, and the quality of the process and appearance is naturally better. Moreover, the design process indirectly affects the quality of production.

2. It can be identified according to the process design and application data of the ultrasonic transducer, but this requirement is very understandable and experienced for the transducer data. Whether the design can be reasonably determined should be based on the selection of materials. The quality of the data indirectly affects the quality of the product. The same specifications of the origin of the data is not the same, the quality will vary greatly.

3. Parameter detection, whether the parameters of the ultrasonic transducer can be matched with the parameters of the electric box, can it reach the ideal effect.





PZT8 35Khz 500W Ultrasonic Welding Transducer with 2PCS Ceramics



35Khz High Frequency Ultrasonic Transducer 500W With 2PCS Ceramics 35mm PZT8 0





35Khz High Frequency Ultrasonic Transducer 500W With 2PCS Ceramics 35mm PZT8 1

Tags:

high frequency ultrasonic transducer,

ultrasonic piezo transducer,

piezoelectric transducer ultrasound
