3000W High Frequency 20Khz Ultrasonic Tube Sealing Machine For Copper Or Aluminum

3000W High Frequency 20Khz Ultrasonic Tube Sealing Machine For Copper Or Aluminum

MOQ: 1 unit
Price: Negotation
Standard Packaging: Packed in wooden case
Delivery Period: 15 workdays
Payment Method: T/T, Western Union
Supply Capacity: 2000 unit per month
Detail Information
Place of Origin
China
Brand Name
QRsonic
Certification
CE
Model Number
QR-F2030A
Products Name:
Ultrasonic Metal Welding
Frequency:
20KHZ
Power:
3000W
Voltage:
220V
Air Pressure:
0.05-0.9Mpa
Dimension Of Generator:
540*380*150mm
Highlight:

ultrasonic welding process

,

ultrasonic welding machine

Product Description

3000W High Frequency 20Khz Ultrasonic Copper or Aluminum Tube Sealing


Description:

Ultrasonic sealing and cutting refers to the welding of metal pipes with ultrasonic waves. It is mainly used for copper and aluminum pipes. The main applications are: sealing of copper pipes for air injection, water dispenser and refrigerator compressor injection; copper pipe sealing for shut-off valves and expansion valves; superconducting Heat pipe type flat solar water heater copper tube sealing; various vacuum devices are vacuumed and sealed. The advantages of ultrasonic sealing and cutting: short welding time, no need for any flux, gas, solder; welding without sparks, fast and environmentally friendly.


Specifications:



Item No QR-F2030A
Power 3000W
Diameter of Tube Φ2-12mm
Air Pressure 0.05-0.9MPa
Frequency 20KHZ
Voltage 220V
Weight of horn 26KG
Dimension of Horn 460*220*1000mm
Generator Size 540*380*150mm




Advantage:



1. The copper tube seal is small in size, light in weight and beautiful in appearance.

2. No open flame, smoke and gas during cutting and welding, environmental protection and safety

3. Does not change the welding target metal itself to arrange the structure; high welding quality

4. The welding material does not melt, not weak metal characteristics

5. The welding metal surface needs to be low, and the oxidation or electroplating can be welded.

6. Easy to operate, short welding time, no need for any flux, gas, solder, cost saving

7. The welding consistency is good, and the automatic alarm function is provided for the welding defective products.

8. Seal the tube to a single wall thickness, completely airtight and not leaking. Ideal for use in refrigeration and air conditioning systems.





Applicable industry:



Mainly used for copper tube sealing after the freon is mainly used in the refrigerator. And the sealing of copper tubes in the refrigeration industry such as refrigerators, freezers, air conditioners, etc., sealing and cutting of copper tubes and aluminum tubes for vacuum devices.

1. Air conditioning HVAC system and refrigerator inflatable tube, injection tube sealing welding

2. Capillary and bulb temperature sensor

3. Other products that require the use of aerated or fluid filled copper or aluminum tubes

4. Weldable metal pipe diameter: 0.5 ~ 10 mm; pipe wall thickness: 0.25~5mm





3000W High Frequency 20Khz Ultrasonic Copper or Aluminum Tube Sealing



3000W High Frequency 20Khz Ultrasonic Tube Sealing Machine For Copper Or Aluminum 0



3000W High Frequency 20Khz Ultrasonic Tube Sealing Machine For Copper Or Aluminum 1
