220V Ultrasonic Metal Welding

220V Ultrasonic Metal Welding

MOQ: 1 unit
Price: Negotation
Standard Packaging: Packed in wooden case
Delivery Period: 15 workdays
Payment Method: T/T, Western Union
Supply Capacity: 2000 unit per month
Detail Information
Place of Origin
China
Brand Name
QRsonic
Certification
CE
Model Number
QR-D2020A
Products Name:
Ultrasonic Metal Welding
Frequency:
20KHZ
Power:
2000W
Voltage:
220V
Air Pressure:
0.05-0.9Mpa
Dimension Of Generator:
540*380*150mm
Highlight:

ultrasonic metal welding equipment

,

ultrasonic welding machine

,

220V Ultrasonic Metal Welding

Product Description

Ultrasonic Metal Welding for Automotive Electronic Control Circuit of Safty Airbag



Description:



The principle of ultrasonic welding is to convert 50/60 Hz power frequency to 20 kHz or more by ultrasonic generator. The converted high frequency electrical energy is again converted by the transducer into mechanical vibration of the same frequency, and then the mechanical motion is transmitted to the welding head through a set of amplitude modulator devices that can change the amplitude. The welding head transfers the vibration energy to the joint of the workpiece to be welded, in which the vibration energy is converted into mechanical energy and thermal energy by friction, so that the workpiece to be processed is welded. Ultrasonic waves can be used not only to weld hard thermoplastics, but also to weld metals.



Ultrasonic welding of plastics generally uses the direction of vibration of the welding head and the vertical of the workpiece. For some thin plastic parts, the direction of vibration of the welding head and the parallel of the workpiece can also be used. When ultrasonic welding of metal, the direction of vibration of the welding head is parallel to the workpiece.



The main components of a set of ultrasonic welding systems include ultrasonic generators, transducers, amplitude modulators, welding head triples, molds and frames. The main function of the frame is to fix and form a pressurizing mechanism.





Specifications:



Item No QR-D2020A QR-D2030A QR-D2050A
Power 2000W 3000W 5000W
Air Pressure 0.05-0.9MPa 0.05-0.9MPa 0.05-0.9MPa
Frequency 20KHZ 20KHZ 20KHZ
Voltage 220V 220V 380V
Weight of horn 55KG 60KG 88KG
Dimension of Horn 550*280*380mm 550*280*430mm 550*380*660mm
Generator Size 540*380*150mm 540*380*150mm 540*380*150mm





Ultrasonic metal welding products:


1. Power battery multilayer positive and negative electrode welding; nickel-hydrogen battery nickel mesh and nickel plate welding
2. Lithium battery, polymer battery copper foil and nickel sheet welding; aluminum foil and aluminum sheet welding; aluminum sheet and nickel sheet welding
3.Automotive wiring harness; wire head forming; wire mutual welding; multiple wires are welded to each other; copper and aluminum wire conversion
4. Wire, cable and various electronic components, contacts, connectors, terminal soldering
5. Solar battery, flat solar heat absorbing plate, aluminum-plastic composite pipe, cold welding, copper and aluminum plate splicing
6. Welding of large current contacts, contacts, dissimilar metal sheets such as electromagnetic switches and non-fuse switches
7. Refrigerator, air conditioner and other industries copper tube sealing; vacuum device copper, aluminum tube sealing and cutting water, airtight





Ultrasonic Metal Welding for Automotive Electronic Control Circuit of Safty Airbag



220V Ultrasonic Metal Welding 0



220V Ultrasonic Metal Welding 1
