3000W Ultrasonic Metal Welding Device Strong Welding Conductivity With Digital Generator

MOQ: 1 unit
Price: Negotation
Standard Packaging: Packed in wooden case
Delivery Period: 15 workdays
Payment Method: T/T, Western Union
Supply Capacity: 2000 unit per month
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
QRsonic
Certification
CE
Model Number
QR-D2030Q
Products Name:
Ultrasonic Metal Welding
Frequency:
20KHZ
Power:
3000W
Voltage:
220V
Air Pressure:
0.05-0.9Mpa
Dimension Of Generator:
400*195*98mm
Highlight:

ultrasonic metal welding equipment

,

ultrasonic welding machine

Product Description

20Khz 3000W Latest Ultrasonic Metal Welding Device Strong Welding Conductivity with Digital Generator



Description:


The latest 20Khz 3000w ultrasonic metal welding machine has the advantages of welding metal products together without changing the metal material structure, and has the characteristics of high strength, welding time period, strong welding conductivity, high efficiency, low cost safety and environmental protection.





Principle:



Ultrasonic metal welding uses high-frequency vibration waves to transmit to two metal surfaces to be welded. Under pressure, the two metal surfaces rub against each other to form a joint between the molecular layers. The advantage is that it is fast, energy-saving, High fusion strength, good electrical conductivity, no spark, close to cold processing; the disadvantage is that the welded metal parts should not be too thick (generally less than or equal to 5mm), the solder joints should not be too large, and need to be pressurized.



Specifications:



Item No QR-D2020A QR-D2030A QR-D2050A QR-D2030Q
Power 2000W 3000W 5000W 3000W
Air Pressure 0.05-0.9MPa 0.05-0.9MPa 0.05-0.9MPa 0.05-0.9MPa
Frequency 20KHZ 20KHZ 20KHZ 20KHZ
Voltage 220V 220V 380V 220V
Weight of horn 55KG 60KG 88KG 60KG
Dimension of Horn 550*280*380mm 550*280*430mm 550*380*660mm 550*280*430mm
Generator Size 540*380*150mm 540*380*150mm 540*380*150mm 400*195*9mm




Advantages:



1. High-quality welding head: Metal welding, as an industrial use, necessarily requires a high-life welding head.

2. High-quality control system: It has three basic control modes: welding energy, time and height. Various quality control softwares meet different needs.

3. Metal welding machines use high-quality transducers: such as 20kHz transducers, they must be able to withstand loads of more than 3kw for a long time. Many companies' transducers, which use ordinary plastic welded transducers, are difficult to distinguish in appearance, which is irresponsible.




20Khz 3000W Latest Ultrasonic Metal Welding Device Strong Welding Conductivity with Digital Generator



3000W Ultrasonic Metal Welding Device Strong Welding Conductivity With Digital Generator 0





3000W Ultrasonic Metal Welding Device Strong Welding Conductivity With Digital Generator 1

Tags:

ultrasonic welding machine,

ultrasonic welding process,

ultrasonic metal welding equipment
