Ultrasonic Probe Type Nozzle 40Khz In Test Tube Spray Injector Silicone Oil Spray
  • name
  • name
  • name
  • name

Ultrasonic Probe Type Nozzle 40Khz In Test Tube Spray Injector Silicone Oil Spray

MOQ: 1 UNIT
Price: Negotation
Standard Packaging: Packed by carton
Payment Method: T/T, Western Union
Supply Capacity: 1000 unit per month
Detail Information
Product Description
Detail Information
Place of Origin
CHINA
Brand Name
FUNSONIC
Certification
CE
Model Number
FSW-4004-L
Production Name:
Ultrasonic Spraying Nozzle
Frequency:
40Khz
Max Power:
50w
Automized Particle Size Range:
15-40μm
Spray Flow:
0.3-5ml
Liquid Viscosity:
<30cps
Particle Size:
<5μm
Application:
In Test Tube Spray Injector Silicone Oil Spray
Highlight:

Test Tube Probe Nozzle

,

Ultrasonic Probe Type Nozzle 40Khz

,

Silicone Oil Spray Nozzle

Product Description

Ultrasonic Probe Type Nozzle 40Khz In Test Tube Spray Injector Silicone Oil Spray





Description:



The probing type (long mouthed) aims to produce reproducible thin lines, down to 0.5mm. In very small volume applications, low pressure air/gas is used to focus spray into very thin lines. The long mouthed design creates the thinnest and clearest lines among all nozzles. Can be applied for in vitro spraying.


The probe type ultrasonic nozzle is an extended type of ultrasonic atomization nozzle. It adopts ultrasonic atomization nozzle technology and extends the ultrasonic nozzle into a narrow space for spraying by extending the front end design of the nozzle. It is mainly used for probing the inner wall of pipelines for spraying applications.


Typical applications include vacuum blood collection tube spraying, syringe silicone oil spraying, etc. FUNSONIC provides a complete ultrasonic spraying solution for vacuum blood collection and spraying. The controllable ultrasonic nozzle can perform ultrasonic spraying with 5-10 parallel heads, and the distance between the two nozzles is only 25mm. It can be directly used in existing vacuum blood collection production lines. Combined with a dedicated precision metering pump, the anticoagulant is evenly sprayed into the inner wall of the vacuum blood collection vessel, with a production speed of up to 12000 tubes per hour.





Parameters:



Model FSW-4004-L
Name Ultrasonic Probe Type Nozzle 40Khz
Frequency 40Khz
Atomized particle size range(μm) 15-40
Spray width(mm) 3-15
Spray flow(ml/min) 0.3-5
Spray height(mm) 1-100
Liquid viscosity (cps) <30
Particle size (μm) <15
Diversion pressure (Mpa) N
Application In Test Tube Spray Injector Silicone Oil Spray





Advantage:



1. Excessive spraying to reduce waste
2. The non clogging nozzle design can minimize maintenance and downtime.
3. Highly controllable spray can produce reliable, repeatable and consistent results.
4. Able to spray ultra-thin and clear lines
5. The kinetic energy of low-speed spray is very small and will not damage or change the most vulnerable cell structure





Ultrasonic Probe Type Nozzle 40Khz In Test Tube Spray Injector Silicone Oil Spray



Ultrasonic Probe Type Nozzle 40Khz In Test Tube Spray Injector Silicone Oil Spray 0Ultrasonic Probe Type Nozzle 40Khz In Test Tube Spray Injector Silicone Oil Spray 1
