| Place of Origin: | China |
|---|---|
| Brand Name: | FUNSONIC |
| Certification: | CE |
| Model Number: | FSD-4005-GL |
| Minimum Order Quantity: | 1 UNIT |
| Price: | Negotation |
| Packaging Details: | Packed by Wooden Case |
| Delivery Time: | 5-8 work days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 1000 unit per month |
| Name: | 40Khz Experimental Liquid Ultrasonic Processing | Frequency: | 40Khz |
|---|---|---|---|
| Power: | 500w | Input Voltage: | 220V±10%，50/60Hz |
| Emitter Materials: | Titanium Alloy | Emitter Type: | Focus Type |
| Durable Temperature: | 0-60℃ | Application: | Ultrasonic Cell Fragmentation |
| Highlight: | High Frequency Ultrasonic Sonochemistry Equipment,40Khz Ultrasonic Sonochemistry Equipment,Ultrasound Sonochemical Protein Cell Fragmentation Extraction |
||
High Frequency 40Khz Ultrasound Sonochemical Protein Cell Fragmentation Extraction
Description:
In modern laboratories, ultrasonic sonochemical equipment is used to destroy cell walls to extract cell contents, such as proteins, without damaging them. A portion of the energy introduced into the cell suspension is converted into heat through friction. In order to avoid thermal damage to the cell contents, the sample is either subjected to intermittent ultrasonic treatment periodically or cooled in a cooling container during ultrasonic treatment. Because the ultrasonic energy forces the sample to cycle repeatedly below the probe and throughout the entire side arm, it is possible to perform uniform ultrasonic treatment on microorganisms. Simultaneously placed in an ice bath, due to the expansion of the glass surface, it can effectively cool the cell contents.
The destruction of cell membranes largely depends on the elasticity of the cells. Cellular components, such as mitochondria or cytoplasm, can be partially disrupted by altering input ultrasound energy and extraction power. For particularly resistant bacteria (such as streptococci), fungi, spores, yeast, or tissue samples, direct destruction can be achieved through micro tips with very high ultrasound amplitudes, as micro tips can input a very large amount of energy into the smallest sample size.
Parameters:
| Model | FSD-4005-GL |
| Name | 40Khz Ultrasonic Cell Fragmentation |
| Frequency | 40Khz |
| Power | 500w |
| Input Voltage | 220V±10%,50/60Hz |
| Emitter Materials | Titanium Alloy |
| Emitter Type | Focus Type |
| Durable Temperature | 0-80℃ |
| Component Accessories | Ultrasonic Generator, Ultrasonic Vibration System, Ultrasonic Horn |
Appication in Biochemistry and Medicine:
1. Destruction of organizational culture
Subcellular components and viruses are destroyed without any damage.
2. Parent child identification
Quickly extract matrix free hemolytic substances from the EDTA blood of the assumed father for parent-child identification (reducing preparation time by approximately 30 minutes).
3. Urology
Biochemical membrane analysis of sperm components.
4. Genetic research
Extract DNA from human body materials.
5. Lipid preparation
The use of ultrasound (20 kHz) to decompose MLV (multilayer liposomes) is the main method for producing SLV (monolayer liposomes).
6. Treatment of smallpox vaccine
Prepare a uniformly distributed infection solution.
High Frequency 40Khz Ultrasound Sonochemical Protein Cell Fragmentation Extraction
