Place of Origin: | China |
---|---|
Brand Name: | QRsonic |
Certification: | CE |
Model Number: | QR-5020-CJ20 |
Minimum Order Quantity: | 1 pcs |
Price: | Negotation |
Packaging Details: | Packed in carton |
Delivery Time: | 3 workdays |
Payment Terms: | T/T, Western Union |
Supply Ability: | 2000pcs per month |
Products Name: | Ultrasonic Replacement Converter | Frequency: | 20 Khz |
---|---|---|---|
Output Power: | 3300 Watt | Joint Bolt: | 1/2-20UNF |
Ceramic Disc Diameter: | 50mm | Capacitance: | 18-20nf |
Amplitude: | 10um | Application: | Ultrasonic Plastic Welding Machine |
High Light: | 3300 watt ultrasonic converter,high power ultrasonic transducer,Branson CJ20 Ultrasonic Converter |
3300W Replacement Branson CJ20 Ultrasonic Converter for All 2000 Series
Description:
Ultrasonic Converters and Ultrasonic Transducers are one in the same. There is one Ultrasonic OEM, Dukane Corporation, that uses the term Transducer. All of the other ultrasonic OEM manufactures such as Branson, Sonics and Materials, Rinco, Telesonics and Herrmann refer to these as Converters or Konverters.
The converter is aptly named because it receives electrical energy from the power supply and converts it into mechanical vibrations. Branson CJ-20 converter (101-135-059) replacement used in all 20KHz 2000, 2000X and DCX series IW, actuator and assembly stand systems that delivers rugged quality and superior value.
Specifications:
Model | QR-5020-CJ20 |
Frequency | 20 khz |
Output power | 3300 watt |
Joint bolt | 1/2-20UNF |
Ceramic disc Diameter | 50mm |
Qty of ceramic discs | 4pcs |
Capacitance | 18-20nf |
Amplitude | 10 um |
Application | Plastic welding machine |
The difference between a titanium alloy transducer and an aluminum alloy transducer:
Aluminum alloy is the most commonly used basic material in ultrasonic waves. Whether it is a transducer, an amplitude modulator or a mold, most of the molds are made of aluminum alloy material, and the appearance is achieved by electroplating or oxidation treatment. Advantages: Aluminum alloy is cheap, easy to process, and low in cost. Disadvantages: It is prone to fatigue fracture, surface decoration is easy to fall off, and the service life is short.
Titanium alloy is a rare metal, and its strength and toughness are the best combined materials. Advantages: no need for surface decoration treatment, to a certain extent, there will be no slipping, cracking, and long service life. Disadvantages: expensive materials, difficult to process, high cost.
Material amplitude difference: Due to the high strength of titanium alloy, it generally has 38-42HRC, while the maximum strength of titanium alloy is only 8-10HRC. The product of the same structure is designed in the ultrasonic wave, and the amplitude of the titanium alloy material is smaller than the amplitude of the aluminum alloy material. The reason is that the strength of the titanium alloy material is high, and the high-strength material weakens part of the amplitude during the amplification and transmission of the ultrasonic wave, and it is advantageous to stabilize the strong wave and filter out the clutter. Make the ultrasonic transmission more stable. If it is necessary to achieve the same amplitude, it is necessary to change the design structure of the titanium alloy product and increase its amplitude design to achieve the required amplitude.
