100w 220V Ultrasonic Metal Welding Machine Copper Wire Inlay To PVC Plate

MOQ:	1 unit
Price:	Negotation
Standard Packaging:	Packed in wooden case
Delivery Period:	10 workdays
Payment Method:	T/T, Western Union
Supply Capacity:	2000 unit per month

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

QRsonic

Certification

Model Number

QR-W60A

Products Name:

Ultrasonic Wire Embedding Machine

Frequency:

60KHZ

Power:

Voltage:

Protective Sleeve:

φ25*110

Welding Head:

Aperture 0.mor 0.5mm

Cooling Compressor Air:

＞0.1MPa/unit

Generator:

Analog Generator

Highlight:

ultrasonic spot welding machine

ultrasonic bonding machine

Product Description

Copper Wire Inlay to PVC Plate By 60Khz Ultrasonic Embedding Parts

Description:

60KHZ ultrasonic intelligent IC smart card welding machine, in the production of Bank card, smart card and VIP, which need to dip tin coils and then welding. Ultrasonic IC smart card welding equipment can be made into one generator to drive 5 to 10 sets welding heads, which will easy for you to use.

Specifications:

Type	QR-W60A
Frequency(KHz)	60KHz
Trigger	External control or manual control
welder head	wear-resisting alloy steel above HRC55°
Threading hole	Φ0.m or Φ0.5mm
Power code	2M or 5M
Generator	Digital generator V6.6 or analog generator ZJS-100
Generator Size	280320140mm(V6.6) 280320150mm(ZJS-100)
Cover dimension	Φ25X100mm
Cover material	Nylon or aluminum
Cooling way	compressed air cooling (Φ4mm conduit)
Speed	0.1-0./s
Thread fixed cycle	length 60000 m/s

Competitive Advantage:

Steady welding point, completely eradicate insufficient solder technically.
The size of welding spots is the same, equality line, good effect on uniformity.
The welding spot is small, wouldn’t increase the weight of the coil, easy to do lamination and encapsulation.
To leave out the immersion tin step before doing welding, save an operator.
After skilled in welding, much faster than the way to use searing iron to do weld.
On the process on manufactory, there is no waste gas, waste rubbish on pollution, runs in quiet and no noise.
To select the frequency 60KHz, one machine could drive 5-10 ultrasonic products, the speed to do welding is much faster.
Low power consumption, to save production cost for manufactory enterprise.

Copper Wire Inlay to PVC Plate By 60Khz Ultrasonic Embedding Parts

100w 220V Ultrasonic Metal Welding Machine Copper Wire Inlay To PVC Plate 0

100w 220V Ultrasonic Metal Welding Machine Copper Wire Inlay To PVC Plate 1
