Place of Origin: | China |
---|---|
Brand Name: | QRsonic |
Certification: | CE |
Model Number: | QR-WD15 |
Minimum Order Quantity: | 1 pcs |
Price: | Negotation |
Packaging Details: | Packed in wooden case |
Delivery Time: | 7 workdays |
Payment Terms: | T/T, Western Union |
Supply Ability: | 2000 pcs per month |
Products Name: | Ultrasonic Power Supply | Frequency: | 15KHZ |
---|---|---|---|
Power: | 2600W | Voltage: | 220V Or 110V |
Generator: | Digital Generator | Application: | Plastic Welding Machine |
Highlight: | ultrasonic sound wave generating device,ultrasonic signal generator |
15Khz 2600w Ultrasonic Wave Generator With Duration Control For Plastic Weld System
Description:
Ultrasonic power sources are often referred to as ultrasonic sources, ultrasonic generators, and ultrasonic electronics boxes. It is a major component of high power ultrasound systems. Its function is to generate a high-power high-frequency AC signal to drive the ultrasonic transducer to work. The high-quality driving power supply must ensure the stable and safe operation of the high-power ultrasonic system. At the same time, it must monitor the operating frequency, load power, capacitive reactance, impedance and other parameters of the transducer in real time, and can carry out power according to different needs of users. Adjustment of parameters such as amplitude and operation mode.
Specifications:
Item No | QR-WD15 |
Power | 2600W |
Generator | Digital generator |
Frequency | 15KHZ |
Voltage | 220V or 110V |
Size | 300*450*170mm |
Application | Plastic Welding Machine |
Net weight | 7Kg |
Several reasons for the large ultrasonic current and the solution:
The following summarizes several reasons for the excessive current of the ultrasonic welding machine in the no-load state, and the method of elimination. Non-professionals can conduct investigations.
The ultrasonic control electric box is also called an ultrasonic generator. It is a device for generating ultrasonic signals. In many cases, the current of the ultrasonic generator is often caused by various reasons. The ultrasonic current is large, and it is necessary to distinguish whether the current of the ultrasonic generator itself is damaged or the current of the ultrasonic load is large. Very simple, remove the ultrasonic output line, and test the current of the ultrasonic generator without load. If it is normal, it means that the ultrasonic vibration system is faulty.
Experience has shown that the large current of the ultrasonic generator is generally caused by the mismatch between the ultrasonic vibration system of the ultrasonic transducer and the ultrasonic generator. In response to this problem, it is necessary to check whether each component of the ultrasonic vibration system is normal, whether the link screw between them is loose, whether there is a crack in the ultrasonic mold or the like.
1. Loose screws between the ultrasonic die and the transducer cause high current. Generally, the method of removing it on a machine that has been used for a period of time is to use a special wrench of the ultrasonic die to see if the die is not locked.
2. Ultrasonic molds or dies are damaged or broken. Generally, they are used on ultrasonic waves that have been used for a long time or for a long time. The method of elimination is to check whether there is crack on the outer surface of the die, or to install it on other ultrasonic systems for testing.
3. Replace the ultrasonic transducer vibrator or ultrasonic die. If the current is too high after replacing the two components, this is normal. This problem can be solved by adjusting the ultrasonic frequency.
15Khz 2600w Ultrasonic Digital Generator with Duration Control for Plastic Weld System
