Portable Ultrasonic Spot Welding Machine
  • name
  • name
  • name
  • name

Portable Ultrasonic Spot Welding Machine

MOQ: 1 unit
Price: Negotation
Standard Packaging: Packed in wooden case
Delivery Period: 10 workdays
Payment Method: T/T, Western Union
Supply Capacity: 2000 unit per month
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
QRsonic
Certification
CE
Model Number
QR-W70D
Products Name:
Ultrasonic Wire Embedding Machine
Frequency:
70KHZ
Power:
50w
Voltage:
220V
Protective Sleeve:
φ16*121mm
Welding Head:
Aperture 0.m Or 0.5mm
Cooling Compressor Air:
＞0.1MPa/unit
Generator:
Digital Generator
Highlight:

ultrasonic spot welding machine

,

ultrasonic bonding machine

,

Portable Ultrasonic Wire Embedding Machine

Product Description

70Khz Ultrasonic Wire Embedding Device Replacement Telsonic Oscillator ​





Principle:



The ultrasonic embedding device penetrates the wire to be implanted into the hole of the head of the embedding device, places the head (welding surface) of the embedding device on the plastic thin plate, activates the ultrasonic device, and performs the routing and embedding. Completed during the routing process. When the line is finished, the entire welding process is also completed.





Specifications:



Type QR-W70D
Frequency(KHz) 70KHz
Trigger External control
welder head Titanium Alloy Material
Threading hole Φ0.m or Φ0.5mm
Power code 5M
Generator Digital generator
Generator Size 155*265*170mm
Cover dimension Φ16X121mm
Cover material Aluminum
Cooling way compressed air cooling (Φ4mm conduit)
Speed 0.1-0./s
Thread fixed cycle length 60000 m/s





Features:



  1. Main features Intelligent search frequency: automatic frequency function to extend the life of the plug.
  2. Installation method: single cabinet, combination cabinet, can control eight embedding rods to work at the same time.
  3. Control mode: multi-point point energy fine adjustment, external PLC / computer signal control, easy to operate.
  4. Button-on function: The welding energy can be adjusted according to the thickness and hot-melt of the welding material, and the operation is simple.
  5. Self-detection function: fault display and error alarm signal.
  6. Appearance: The body design is light, beautiful and durable, and has good heat dissipation performance.
  7. Stability: Long working hours, uniform energy output.





Advantages:



Intelligent frequency search, extending the life of the buried wire 2-3 times.

No immersion in tin before soldering, reducing process and cost.

The matching power is powerful, and the embedding head and the ultrasonic generator can be interchanged at will.

Multi-point power control, ultra-high speed embedding, good consistency.

It solves the problem of heat generation of the device when embedding, and can work for a long time.

Standardized design can directly replace imported products, environmental protection and safety.





70Khz Ultrasonic Wire Embedding Device Replacement Telsonic Oscillator



Portable Ultrasonic Spot Welding Machine 0





Portable Ultrasonic Spot Welding Machine 1
